Gullies in Wirtz Crater

Highlighted Portion of HiRISE Image PSP_001349_1310

This HiRISE image of gullies in Wirtz Crater reveals fine structural details of these fluvial landforms. In the upper regions (near the middle left), the gullies have cut deep V-shaped valley forms into the steep crater walls. Downhill, where the slope flattens somewhat, the gullies have cut less deeply into the crater floor and are braided in appearance. In some places bedforms—or features typically found in terrestrial rivers and streams—can be discerned, particularly small, streamlined features or bars along more braided sections. Finally, as the gullies reach the crater floor, near the center of the image, they form fan deposits where transported sediment accumulates.

Image PSP_001349_1310 was taken by the High Resolution Imaging Science Experiment (HiRISE) camera onboard the Mars Reconnaissance Orbiter spacecraft on November 9, 2006. The complete image is centered at -48.6 degrees latitude, 335.3 degrees East longitude. The range to the target site was 250.4 km (156.5 miles). At this distance the image scale is 50.1 cm/pixel (with 2 x 2 binning) so objects ~150 cm across are resolved. The image shown here [below] has been map-projected to 50 cm/pixel and north is up. The image was taken at a local Mars time of 3:42 PM and the scene is illuminated from the west with a solar incidence angle of 83 degrees, thus the sun was about 7 degrees above the horizon. At a solar longitude of 132.9 degrees, the season on Mars is Northern Summer.

HiRISE Image PSP_001349_1310

Images from the High Resolution Imaging Science Experiment and additional information about the Mars Reconnaissance Orbiter are available online at:

http://hirise.lpl.arizona.edu/

or

http://marsoweb.nas.nasa.gov/HiRISE/

For information about NASA and agency programs on the Web, visit: http://www.nasa.gov. NASA's Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the Mars Reconnaissance Orbiter for NASA's Science Mission Directorate, Washington. Lockheed Martin Space Systems is the prime contractor for the project and built the spacecraft. The HiRISE camera was built by Ball Aerospace and Technology Corporation and is operated by the University of Arizona.

Previous Image

Next Image

Image Product Pixel Dimensions File Size
Small JPG 512
x
823
124
KBytes
Large JPG 2048
x
3293
2.2
MBytes
Full-Scale JP2 13122
x
21099
159
MBytes
Products for PSP_001349_1310
Note

The highest resolution image is provided in the JPEG-2000 (JP2) format. A JP2 viewer application and browser plug-in may be freely obtained for Mac OS X and Windows platforms: ExpressView by LizardTech, a Celartem Technology Inc. company.
