Active Flows on Steep Slopes in Ganges Chasma
NASA/JPL/University of Arizona
Active Flows on Steep Slopes in Ganges Chasma
ESP_049981_1710  Science Theme: Geologic Contacts/Stratigraphy


AUDIO

Listen to the text

WALLPAPER

800  1024
1152  1280
1440  1600
1920  2048
2560  2880
2736  4500
4K  8K

HIFLYER

PDF, 11 x 17 in

HISLIDES

PowerPoint
Keynote
PDF
This image covers a steep west-facing slope in southwestern Ganges Chasma, north of the larger canyons of Valles Marineris. The spot was targeted both for the bedrock exposures and to look for active slope processes.

We see two distinct flow deposits: lobate flows that are relatively bright, sometimes with dark fringes, and very thin brownish lines that resemble recurring slope lineae (or “RSL”). Both flows emanate from rocky alcoves. The RSL are superimposed on the lobate deposits (perhaps rocky debris flows), so they are younger and more active.

The possible role of water in forming the debris flows and RSL are the subjects of continuing debate among scientists. We will acquire more images here to see if the candidate RSL are active.

Written by: Alfred McEwen (audio: Tre Gibbs)  (31 May 2017)
twitter  •  facebook  •  google+  •  tumblr

Acquisition date
26 March 2017

Local Mars time:
14:05

Latitude (centered)
-8.769°

Longitude (East)
307.860°

Range to target site
264.5 km (165.3 miles)

Original image scale range
52.9 cm/pixel (with 2 x 2 binning) so objects ~159 cm across are resolved

Map projected scale
50 cm/pixel and North is up

Map projection
Equirectangular

Emission angle:
2.3°

Phase angle:
28.7°

Solar incidence angle
31°, with the Sun about 59° above the horizon

Solar longitude
339.1°, Northern Winter

For non-map projected images
North azimuth:  97°
Sub-solar azimuth:  3.8°
