A Frost Enhanced Landscape
NASA/JPL/University of Arizona
A Frost Enhanced Landscape
ESP_042895_2495  Science Theme: Glacial/Periglacial Processes
twitter  •  tumblr

HICLIP
1080p (MP4)
Audio (MP3)

WALLPAPER
800
1024
1152
1280
1440
1600
1920
2048
2560
2880
4K

HIFLYER
PDF (11 x 17)

HISLIDES
PowerPoint
Keynote
PDF

The arc of hills in this image is the rim of an old and infilled impact crater. The sediments that were deposited within the crater have since formed polygonal cracks due to repeated cycles of freezing and thawing. The process of polygon formation is common at these polar latitudes, but polygons are not always as striking as they are here. In this image, the polygons have been highlighted by persistent frost in the cracks.

The crater rim constrains the polygon formation within the crater close to the rim, creating a spoke and ring pattern of cracks. This leads to more rectangular polygons than those near the center of the crater. The polygons close to the center of the crater display a more typical pattern. A closer look shows some of these central polygons, which have smaller polygons within them, and smaller polygons within those smaller polygons, which makes for a natural fractal!

Written by: HiRISE Targeting Specialists (audio: Tre Gibbs)  (23 December 2015)

Acquisition date
20 September 2015

Local Mars time
14:20

Latitude (centered)
69.086°

Longitude (East)
68.429°

Spacecraft altitude
313.7 km (194.9 miles)

Original image scale range
31.4 cm/pixel (with 1 x 1 binning) so objects ~94 cm across are resolved

Map projected scale
25 cm/pixel

Map projection
Polarstereographic

Emission angle
2.9°

Phase angle
58.6°

Solar incidence angle
56°, with the Sun about 34° above the horizon

Solar longitude
44.3°, Northern Spring

For non-map projected images
North azimuth:  100°
Sub-solar azimuth:  320.3°
JPEG
Black and white
map projected  non-map

IRB color
map projected  non-map

Merged IRB
map projected

Merged RGB
map projected

RGB color
non-map projected

JP2
Black and white
map-projected   (632MB)

IRB color
map-projected   (334MB)

JP2 EXTRAS
Black and white
map-projected  (273MB)
non-map           (282MB)

IRB color
map projected  (99MB)
non-map           (240MB)

Merged IRB
map projected  (186MB)

Merged RGB
map-projected  (171MB)

RGB color
non map           (213MB)
ADDITIONAL INFORMATION
B&W label
Color label
Merged IRB label
Merged RGB label
EDR products
HiView

NB
IRB: infrared-red-blue
RGB: red-green-blue
About color products (PDF)

Black & white is 5 km across; enhanced color about 1 km
For scale, use JPEG/JP2 black & white map-projected images
